Coltri Ergo TPS Electric Compressor
Description
The ERGO TPS is the perfect solution for those needing a compact, high-performance breathing air compressor. Equipped with four TPS (Tropical Plus Superdry) pumping units, the ERGO TPS runs on electric motors or engines, offering options from Honda for petrol models and Kohler for diesel compressors. Its control panel includes a comprehensive monitoring system with pressure gauges, autostop with an adjustable electronic pressure switch, automatic condensate drainage, and rotation direction control. With two high-pressure hose connections and an advanced filtration system featuring dual Hyperfilters, the ERGO TPS delivers superior air quality. A remote charging panel is also available as an optional upgrade.
Download the Technical Data Sheet for full specifications and optional extras.
Download the Technical Data Sheet for full specifications and optional extras.
Key Features
- Type of gas: Breathing air EN 12021 - Nitrox 40% max O2 - Helium - Nitrogen
- Intake pressure: Atmospheric max 300 bar
- Nominal pressure: 250 bar / 330 bar / 360 bar
- Working pressure: 232 bar / 300 bar / 330 bar
- Max working pressure: 232 bar / 420 bar
- Permissible ambient temperature range: -10° C ÷ +40° C
- Permissible altitude: 0 ÷ 1.500 m SLM
- Max permissible tilt: 15°
- Design: Open
- Operating voltage, standard: 400 V, 50 Hz
- Other operating voltage: 230 V, 50 Hz / 440 V, 60 Hz / 230 V, 60 Hz
- Oil: Synthetic Coltri Oil ST 755
- Oil change interval: 1 year / 1.000 h
- Frame: Steel - Colour RAL 5002 - powder coating painting - scratch proof
